- Slocable Single Core 1x2.5/4/6/10 mm2 Kabel Solar Panel Cable H1Z2Z2-K
4.918 global reviews
Review Images
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
Tokopedia customer review
About this product
Kabel Single Core untuk sistem solar panel anda!
Tersedia variasi berbagai ukuran dan warna kabel apabila anda memiliki kekurangan dalam rangkaian solar panel tinggal beli sesuai kebutuhannya!
Spesifikasi:
Material:
Conductor: tembaga dilapis timah
Insulation: XLPE (Hitam) bebas halogen
Jacket: XLPE (Hitam) bebas halogen, UV Resisten
Standard H1Z2Z2-K (TUV Certified)
Ukuran: 1 x 2.5 mm2 / 14 AWG
Conductor Structure: 48 x diameter 0.25 mm
Outer Diameter: 5.4 mm
Max DC Resistance at 20 Celsius: 8.06 ohm/km
Rated Voltage: 1500 V DC
Rated Current: 30 A
1 ROLL KABEL UTUH = 100 METER
Ukuran: 1 x 4 mm2 / 12 AWG
Conductor Structure: 56 x diameter 0.285 mm
Outer Diameter: 6.1 mm
Max DC Resistance at 20 Celsius: 4.97 ohm/km
Rated Voltage: 1500 V DC
Rated Current: 50 A
1 ROLL KABEL UTUH = 100 METER
Ukuran: 1 x 6 mm2 / 10 AWG
Conductor Structure: 78 x diameter 0.3 mm
Outer Diameter: 6.4 mm
Max DC Resistance at 20 Celsius: 3.52 ohm/km
Rated Voltage: 1500 V DC
Rated Current: 70 A
1 ROLL KABEL UTUH = 100 METER
Ukuran: 1 x 10 mm2 / 8 AWG
Conductor Structure: 78 x diameter 0.4 mm
Outer Diameter: 7.3 mm
Max DC Resistance at 20 Celsius: 2.12 ohm/km
Rated Voltage: 1500 V DC
Rated Current: 95 A
1 ROLL KABEL UTUH = 100 METER
PEMBELIAN PER METER (1 UNIT = 1 METER)
PEMBELIAN SESUAI VARIAN
VARIAN MERAH HANYA UNTUK KABEL MERAH (+)
VARIAN HITAM HANYA UNTUK KABEL HITAM (-)
VARIAN MERAH & HITAM UNTUK SEPASANG KABEL MERAH DAN HITAM
Product description
Kabel Single Core untuk sistem solar panel anda!
Tersedia variasi berbagai ukuran dan warna kabel apabila anda memiliki kekurangan dalam rangkaian solar panel tinggal beli sesuai kebutuhannya!
Spesifikasi:
Material:
Conductor: tembaga dilapis timah
Insulation: XLPE (Hitam) bebas halogen
Jacket: XLPE (Hitam) bebas halogen, UV Resisten
Standard H1Z2Z2-K (TUV Certified)
Ukuran: 1 x 2.5 mm2 / 14 AWG
Conductor Structure: 48 x diameter 0.25 mm
Outer Diameter: 5.4 mm
Max DC Resistance at 20 Celsius: 8.06 ohm/km
Rated Voltage: 1500 V DC
Rated Current: 30 A
1 ROLL KABEL UTUH = 100 METER
Ukuran: 1 x 4 mm2 / 12 AWG
Conductor Structure: 56 x diameter 0.285 mm
Outer Diameter: 6.1 mm
Max DC Resistance at 20 Celsius: 4.97 ohm/km
Rated Voltage: 1500 V DC
Rated Current: 50 A
1 ROLL KABEL UTUH = 100 METER
Ukuran: 1 x 6 mm2 / 10 AWG
Conductor Structure: 78 x diameter 0.3 mm
Outer Diameter: 6.4 mm
Max DC Resistance at 20 Celsius: 3.52 ohm/km
Rated Voltage: 1500 V DC
Rated Current: 70 A
1 ROLL KABEL UTUH = 100 METER
Ukuran: 1 x 10 mm2 / 8 AWG
Conductor Structure: 78 x diameter 0.4 mm
Outer Diameter: 7.3 mm
Max DC Resistance at 20 Celsius: 2.12 ohm/km
Rated Voltage: 1500 V DC
Rated Current: 95 A
1 ROLL KABEL UTUH = 100 METER
PEMBELIAN PER METER (1 UNIT = 1 METER)
PEMBELIAN SESUAI VARIAN
VARIAN MERAH HANYA UNTUK KABEL MERAH (+)
VARIAN HITAM HANYA UNTUK KABEL HITAM (-)
VARIAN MERAH & HITAM UNTUK SEPASANG KABEL MERAH DAN HITAMView more
Rp13.500
From Rp11.500 shipping on this order
Slocable Single Core 1x2.5/4/6/10 mm2 Kabel Solar Panel Cable H1Z2Z2-K
4.9(18)
4.1K sold
Ukuran:Please select
1x2.5mm2
1x4mm2
1x6mm2
1x10mm2Warna:Please select
Merah
Hitam
Merah & Hitam
