TECHNICAL SPECIFICATIONS :MODEL : SCR6048MPPT Efficiency : >99%System Voltage : 12V/24V/48V (Auto)Dimension (W x D x H) : 200 x 168 x 94mm INPUTMax. PV Input Voltage : 170VDCMPPT Operating Voltage Range :* 12V: 18VDC-150VDC* 24V: 34VDC-150VDC* 48 : 65VDC-150VDCLow Voltage Protection :* 12V: 16VDC* 24V: 30VDC* 48V: 60VDCHigh-Voltage Protection : 170VDCPV Rated Input Power :* 12V: 855W* 24V: 1710W* 48V: 3420W DC LOAD OUTPUTLoad Voltage : Same as Battery VoltageLoad Current : 20ALoad Control Mode : ON/OFF, PV Voltage Control, Time Control, PV + Time Control CHARGEBattery Type : Sealed Lead Acid, Gel, Flooded, Lithium-Ion, User-DefinedCharging Mode : MPPT (Maximum Power Point Tracking)Charging Current : 60ACharging Method : Three-Stage: CC (Constant Current) - CV (Constant Voltage) - CF (Float Charge)Temperature Compensation : -3mV/°C/2V (Default)Float Charging Voltage (Lead Acid Default) :* 12V: 13.8VDC (Settable)* 24V: 29.0VDC (Settable)* 48V: 55.2VDC (Settable)Boost Charging Voltage (Lead Acid Default) :* 12V: 14.5VDC (Settable)* 24V: 29.0VDC (Settable)* 48V: 58.0VDC (Settable) SYSTEMProtection Function : Input Low/Over Voltage, Input/Output Polarity Reverse Connection, Short Circuit, Over Temperature, Battery Shedding, etc.Display : Touch LCD+LEDCooling Method : Forced Air CoolingStandby Power : Communication : RS485 ENVIRONMENTRelative Humidity : 0~90% RH (Non-Condensing)Altitude : < 3000mOperating Temperature : -20°C~+40°CStorage Temperature : -40°C~+75°CProtection Level : IP21
