Product description
CON-0008
========
Deskripsi:
=================================
Terminal PCB block 2 pin. Digunakan sebagai port input atau output di PCB. Terminal ini sangat sering sekali digunakan, karena memudahkan kita untuk memasang dan membuka I/O tanpa perlu soket ataupun menyoldernya
Silahkan di ORDER gan !!!! :D
Spesifications:
=================================
- Type : Terminal Blocks
- Maximum Current Rating : 15A
- Contact Plating : Tin/Zinc
- Body Orientation : Straight
- Contact Material : Brass/Steel
- Housing Material : Thermoplastic
- Housing Color : Blue
- Wire Size : 14-22AWG
- Number of Contacts : 2
- Number of Rows : 1
- Maximum Voltage Rating : 300VAC
- Minimum Operating Temperature : -30C
- Maximum Operating Temperature : 105C
- Mounting : Through Hole
- Termination Method : Solderable
- Pitch : 5.08mm
- Product Depth : 9mm
- Product Height : 13mm
- Product Length : 10.86mm
- Product Type : Connector Terminal Blocks
Paket :
=================================
- 1x TERMINAL PCB BLOCK SCREW 2 PIN KF301-2P BLUE BIRU
UNTUK HARGA GROSIR CHAT US ^^
