Overload Thermal Protector Circuit Breaker Kuoyuh 2.5A 3A 4A 5A 6A 7A 8A 9A 10A 11A 12A 13A 14A 15A 16A 17A 18A 19A 20A 21A 22A 23A 24A 25A 26A 27A 28A 29A 30A Switch Overload Protector Sibel Pompa Satelit Submersible Amper
Sold by Wikimesin
4.9(11)
63 sold
Select options
Select
Shipping
From Rp12.000
Est. delivery by May 12 - May 17
Specifications
Customer reviews (11)
i**🌺
Item: 7A
Barang nya bagus, sesuai dengan yang di pesan, harganya juga worit parah sihhhh
Pokonya bagus bangettt🤩
More
September 15, 2024
N**m
Item: 6A
Pengiriman barang cepat dan barangx sesuai pesanan dan sdh dipasang.... berhasil dan mantap
April 14, 2024
f**5
Item: 3A
Bagus,,sesuai
March 10, 2025
n**o a**s
Item: 7A
Barang oke
September 6, 2024
A**i
Item: 8A
Mantull
September 1, 2023
1**4
Item: 10A
Sesuai
March 6, 2025
P**t
Item: 12A
👍👍👍
January 5, 2025
p**a
Item: 7A
Ok
September 15, 2023
p**a
Item: 10A
Ok
September 15, 2023
** l**a
Item: 6A
Ok
June 11, 2024
!**k
Item: 6A
Ok
September 18, 2024
Wikimesin
6 items
About this product
Jenis GaransiTanpa Garansi
BrandKUOYUH
Product description
[ORIGINAL TAIWAN KUOYUH] - [FREE CAP & RING / NUT]
READY STOCK
Note: Hati-hati dengan produk merek tidak jelas atau barang tiruan dan berkualitas jelek, jangan hanya karna harga murah Anda membeli produk kualitas jelek dan palsu.
KUOYUH SERIES 88 ASLI 100% DAN TOP SELLING DI HAMPIR SELURU NEGARA BESAR DI DUNIA
Kuoyuh Overload Series 88 dapat digunakan pada berbagai jenis mesin atau perangkat elektronik, sebagai contoh, overload kuoyuh ini banyak digunakan di mesin pompa, genset, kompresor, mobil / motor dan lain nya yang membutuhkan pengamanan.
INFO:
Technical Data :
- Current Rating Range : 2.5A-30A
- Input Voltage Rating : 125/250V AC; 32V DC - 50V DC - Frequency : 50/60Hz
- Interrupting Capacity : 125/250V AC x 1000A(UL 1077)
- Max Internal Resistance :
- Typical Life : 1000 Operations at 200% overload
- Insulation Co-ordination : Rated impulse withstand voltage 2.5kV
- Dielectric Strengh : > 1500V AC/min - Insulation Resistance : > 100MOHM (DC 500V)
- Degree of protection : Terminal Area IP00, Operating Area IP40 MECHANICAL/ENVIRONMENTAL DATA
- Operating Ambient Temperature : -10C to +60C
- Termination : 250" (6.35mm) quick connects or solder terminals
- Mounting : Various options Compliance With RoHS
- The product accords with the requirement oh ROHS (2011/65/EU)
- Contacts use Exempted item of RoHS Directive 2010/571/EU 8(a) Compliance With Reach, PAHS, PH1, PH2, PH3
- Ignition Proof : Yes, UL PEQZ2.E155159 Typical Application
- Transforms, Motors, Battery Chargers, Power Supplies, Appliances, Extra Low Voltage Systems, Machinery, etc.
Calibration at 25C
•100% of Rated Current : Hold, No Trip
•150% of Rated Current : Trip Within 1 Hour
•200% of Rated Current : 5 - 30 sec Trip
•300% of Rated Current : 1.5- 5.0 sec Trip
Note: - Sparepart dan accessoris tidak memiliki garansi - Garansi diluar dari pergantian part yang diakibatkan oleh pemakaian.
