(Garansi satu tahun)7018B/7010B Head Unit Mobil Double Din 7 Inch Bluetooth Audio Car MP3 MP5 Player In Touch Screen Radio dengan Layar TFT 440 x 240 dan Kamera Mundur 12LED

● Build-in Bluetooth V2.0 hands-free call.

● Adopt 440 x 240 resolution 26 million full color 7-inch TFT display screen.

● One-way video output, one-way rearview video output, one-way audio output.

● High definition FM audio function and 18 stations preset.

● Support IR wireless remote controller.

● Firmware update, 24 hours digital clock, date.

● Support RMVB / RM / FLV / 3GP / MPEG / DVIX / XVID / DTA / VOB / AVI video file format.

● Support MP3 / WMA / WMV / OGG / APE / ACC / FLAC audio file format.

● Support JPEG / BMP / GIF / TIF image format scan.

● Support high capacity TF / MMC card up to 32G (not included), USB driver, MP5 player.

● Support the order of play / browse play / single repeat / random play / previous / next / fast forward / rewind.

● Electronic type bass / treble, left and right balance, front and back balance, volume control.

● Radio function, support for semi-automatic search / manually search for / frequency fine-tune, 18 saved channels.

● Power and memory function, memory power outages radio reception quality in / playback of the state.

● Variety of audio options: Jazz / pop / rock / classic and so on.

● Support subwoofer (left and right channel stereo).

● Maximum power 4 x 60W, 4 channel powered power amplifier output can be accessed by four horn.

● Front and rear left and right / left and right channel isolation.

● Electronic seismic / over-voltage / over-current protection.

● Language: Chinese, English, Russian, German, Spanish.

【Parameter】

- Frequency response: 20Hz - 20KHz

- Loudspeaker impedance: 4 - 8 Ohm

- Display language: English

Remote Control

- Build-in lithium cell: CR2025 3V

- Remote range: 5m

FM

- FM frequency: 87.5 - 108MHz

- Sensitivity: 25dB

- Selectivity: 60dB

- Separation: 35dB

【Isi Kemasan】

1 x pemutar MP5

2X kabel

1X kendali jarak jauh

Important notice before installation:

Yellow line (for memory wire) connected to the battery constant current positive, the machine will have memory function.

Red line pick the key to the ACC line, this line is also positive, control power switch. Black wire connected to the negative power supply.

Blue line connected lift the antenna or subwoofer REM control line, if not have do not connected, wrapped up with rubberized fabric.

The remaining eight wires(gray white green purple) are speaker line, a group of colors corresponding to a pair of speaker lines (positive and negative).

Please pay attention to check whether the original car speaker cable if contact iron (the original car speaker wire welding to the metal, or a speaker only a line thow out, called contact iron). contact iron will cause our high-power machine without sound, please test it with a multimeter before install, if contact iron, please disconnect and then install.

【Jaminan setelah penjualan】

*Jika Anda menerima masalah kualitas produk (layar apa pun rusak atau tidak ada masalah suku cadang), silakan ambil foto atau video dan hubungi layanan pelanggan sesegera mungkin. Kami mendukung pengembalian dan pertukaran tanpa-musim 7 hari!
