DC3.6-4.8V 50KV Step up Power Module Small Volume High Voltage Generator Pulse High Voltage Module Electric Shock Arc Board

Kami Adalah Sumber Tangan Pertama, Penjualan Skala Besar, Harga Eceran Sama Dengan Harga Grosir

Brand Name : Aideepen

Usage : Pulse

Origin : Mainland China

Certification : none

High voltage two-pole discharge distance : 5-15mm

DC3.6-4.8V 50KV Boost Step up Power Module Small Volume High Voltage Generator Pulse Current Test High Voltage Module Electric Shock Arc Board

Product Features:

1. This high-voltage module is made using the Tesla coil principle

2. Made of high-quality materials, durable and practical

3. Small size, high efficiency, violent discharge strength

4. Pulse high and low pressure integrated type, more convenient to use

5. Wide range of applications, can be used as a high-voltage source in general experiments, electronic instruments, negative ion generators, and scientific small productions

Parameter:

Input voltage: DC3.6-4.8V

Input current: 2A-5A

High pressure type: pulse high and low voltage integrated type

Module size: 50*22*19mm

High voltage two-pole discharge distance: 5-15mm

Correct use:

Step 1: First fix the distance between the ends of the two wires of the same color of the module within (0.5 - 1) cm

Step 2: The two red and green wires at the other end are connected to the battery required for the module to work, the red line positive and green lines are negative, according to the module work needs: one or two 3.7V rechargeable lithium batteries are connected in series

Notes:

1. Ordinary dry batteries have no capacity after testing and cannot drive the module to work.

2. The principle of the module is that the input current is converted into high voltage and output in the form of an arc, so the capacity of the battery determines the output arc effect of the module! Be sure to control the power-on working time within 10 seconds and take intermittent discharge. Beyond fragile! We are not responsible!

3. Within the specified range, the smaller the voltage and current you input, the shorter the arc that can be pulled, and the use of incorrect voltage to pull the arc for a long time is easy to damage the module.

Package List:

High voltage generator*1
