Tenda O1-5G 5GHz 9dBi 11AC 867Mbps Outdoor CPE

PN: 01 Model O1-5G Dimension 132*72*46.3mm Deployment Pole/Wall Mount Application Scenarios PtP and PtMP wireless connection for Privated ISP access or CCTV Surveillance Frequency Range 5GHz Compliant Standards IEEE 802.11a/n/ac Maximum Wireless Rate 867Mbps Interfaces 1*10/100Mbps LAN Port Antenna Polarization Dual Polarization Antennas Gain 9dBi Antenna Beamwidth Horizontal: 30° Vertical: 30° Elevation: 30° Reset Button 1*Reset Button Power Consumption 4.7W Waterproof Level IP65 LED Indicator PoE/LAN,LED1,LED2 Power Method 12V 1A Passive PoE 12V 1A DC Passive PoE Passive power over ethernet via PoE/LAN (+4,5pins -7,8pins ) up to 60 meters Voltage range: 9-13V DC Reception Sensitivity 11a 6Mbps -92dBm±1.5dBm 11n MCS7 HT20 -72dBm±1.5dBm 11ac MCS9 HT80 -64dBm±1.5dBm Operating mode AP/Station Enable/Disable Wireless Radio Support SSID Hidden Support Wireless Client isolation Support Channel Bandwidth 20/40/80MHz Channel Shift Support Client Limitation For SSID Support Wireless Access Control Support Transmission Power Adjustable power by 1dBm WMM Capable Support APSD Capable Support Wireless Security 64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK Transparent Bridge Support VPN Pass-Through PPTP,L2TP Schedule Reboot Support Page Timeout Support Ping Watchdog Support Time and Date Setting Support Firmware upgrade Support Backup/Restore Configuration Support Username Managerment Support System Logs Support Managed By Controller PC Software -- CPE Assistant Package Contents 1*5GHz 9dBi 11AC 867Mbps Outdoor CPE 1*Power Adapter 1*PoE Injector 1*Quick Installation Guide Operation Temperature -30℃ ~ 60℃ Storage Temperature -40℃ ~ 70℃ Operating Humidity 10%~90% non-condensing Storage Humidity 10%~90% non-condensing Default login IP 192.168.2.1 Default Login Username admin Default Login Password admin Certification FCC/CE/RoHS GARANSI RESMI TENDA 2 TAHUN (HARGA JUAL SUDAH TERMASUK PPN & BISA REQUEST FAKTUR PAJAK)
