Rp1.650.000
MOXA TCC-100I Serial Converters Serial Konverter RS-232 to RS-485/422
Sold by Edison Electrical
7 sold
Select options
Select
Shipping
From Rp11.500
Est. delivery by May 11 - May 16
Specifications
Edison Electrical
881 items
Shop performance
Better than 78% of other shops
Ships within 2 days
100%
Responds within 24 hours
100%
About this product
Jenis GaransiGaransi Pabrik Produksi
Brandmoxa
Product description
MOXA TCC-100I Serial Converters Serial Konverter RS-232 to RS-485/422
Features and Benefits
RS-232 to RS-422 conversion with RTS/CTS support
RS-232 to 2-wire or 4-wire RS-485 conversion
Wall mounting and DIN-rail mounting
2 kV isolation protection (TCC-100I)
Plug-in terminal block for easy RS-422/485 wiring
LED indicators for power, Tx, Rx
Wide-temperature model available for -20 to 60°C environments
Serial Interface
Baudrate 50 bps to 921.6 kbps (supports non-standard baudrates)
Connector Terminal block
Isolation TCC-100I/100I-T: 2 kV (-I model)
No. of Ports 2
Pull High/Low Resistor for RS-485 1 kilo-ohm, 150 kilo-ohms
RS-485 Data Direction Control ADDC (automatic data direction control)
Serial Standards RS-232, RS-422, RS-485
Terminator for RS-485 N/A, 120 ohms, 120 kilo-ohms
Serial Signals
RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS-422 Tx+, Tx-, Rx+, Rx-, GND
RS-485-4w Tx+, Tx-, Rx+, Rx-, GND
RS-485-2w Data+, Data-, GND
2
Power Parameters
Input Current TCC-100/100-T: 50 to 85 mA @ 12 to 48 VDC
TCC-100I/100I-T: 150 mA @ 12 to 48 VDC
Input Voltage 12 to 48 VDC
No. of Power Inputs 1
Overload Current Protection Supported
Power Connector Terminal block (for DC models)
Power Consumption TCC-100/100-T: 50 to 85 mA @ 12 to 48 VDC
TCC-100I/100I-T: 150 mA @ 12 to 48 VDC
Package Contents
Device 1 x TCC-100/100I Series converter
Installation Kit 1 x DIN-rail kit
1 x rubber stand
Cable 1 x terminal block to power jack converter
Documentation 1 x quick installation guide
1 x warranty card
Warranty 3 Years
