SHARP IR Sensor jarak infrared GP2Y0E03 4-50cm analog output + cable

The GP2Y0E03 is a distance measuring sensor unit, composed of an integrated combination of CMOS image sensor and IR-LED. The variety of the reflectivity of the object, the environmental temperature and the operating duration are not influenced easily to the distance detection because of adopting the triangulation method. This device outputs the distance as digital (I #39;C) data. So this sensor can also be used as a proximity sensor. Features: Infrared LED and CMOS image sensor with built-in signal processing circuit Distance measuring range : 4 to 50 cm Low voltage operation : Min 2.7V Compact size (16.7 11.0 5.2mm) High-precision measurement Digital(I #39;C) / Analog output type Specifications: Current - Supply:36mA Operating Temperature:-10C ~ 60C (TA) Output Type:I #39;C Sensing Distance:4 ~ 50cm
