Motherboard AMD Ryzen Asrock B550M - HDV Socket AM4 5000 Series



kondisi Baru

Garansi Resmi





Supports 3rd Gen AMD AM4 Ryzen / Future AMD Ryzen Processors

6 Power Phase Design

Supports DDR4 4733+ (OC)

1 PCIe 4.0 x16, 1 PCIe 3.0 x1

Graphics Output Options: HDMI, DVI-D, D-Sub

7.1 CH HD Audio (Realtek ALC887 Audio Codec)

4 SATA3, 1 Hyper M.2 (PCIe Gen4 x4 & SATA3)

6 USB 3.2 Gen1 (2 Front, 4 Rear)

Gigabit LAN



CPU

- Supports 3rd Gen AMD AM4 Ryzen / future AMD Ryzen Processors*

- 6 Power Phase design

Memory

- Dual Channel DDR4 Memory Technology

- 2 x DDR4 DIMM Slots

- AMD Ryzen series CPU support DDR4 4600+(OC) / 4533(OC) / 4466(OC) / 4400(OC) / 4333(OC) / 4333(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3800(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, un-buffered memory*

- Supports "Plug and Play"

Graphics

- Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU*

- DirectX 12, Pixel Shader 5.0

- Shared memory default 2GB. Max Shared memory supports up to 16GB.**

- Three graphics output options: D-Sub, DVI-D and HDMI

- Supports Triple Monitor

- Supports HDMI 2.1 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz

- Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz

- Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz

Audio

- 7.1 CH HD Audio (Realtek ALC887 Audio Codec)

LAN

- PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111H

- Supports Wake-On-LAN

- Supports Lightning/ESD Protection

Storage

- 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug

- 1 x Hyper M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen4x4

Connector

- 1 x SPI TPM Header

- 1 x COM Port Header

- 1 x Chassis Intrusion and Speaker Header

- 1 x CPU Fan Connector (4-pin)*

- 2 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)**

- 1 x 24 pin ATX Power Connector

Form Factor

- Micro ATX Form Factor: 9.0-in x 7.9-in, 23.0 cm x 20.1 cm
